Install Zerotier One on UniFi Cloud Key

Run the following commands on your UniFi Cloud Key:

curl -s https://install.zerotier.com | bash

Output:

*** ZeroTier One Quick Install for Unix-like Systems

*** Tested distributions and architectures:
***   MacOS (10.7+) on x86_64 (just installs ZeroTier One.pkg)
***   Debian (7+) on x86_64, x86, arm, and arm64
***   RedHat/CentOS (6+) on x86_64 and x86
***   Fedora (16+) on x86_64 and x86
***   SuSE (12+) on x86_64 and x86
***   Mint (18+) on x86_64, x86, arm, and arm64

*** Please report problems to [email protected] and we will try to fix.

*** Detecting Linux Distribution

*** Found Debian "jessie" (or similar), creating /etc/apt/sources.list.d/zerotier.list
OK

*** Installing zerotier-one package...
Hit https://deb.nodesource.com jessie InRelease
Hit https://deb.nodesource.com jessie/main armhf Packages
Get:1 http://download.zerotier.com jessie InRelease [20.9 kB]
Ign http://httpredir.debian.org jessie InRelease
Get:2 http://security.debian.org jessie/updates InRelease [44.9 kB]
Hit http://www.ubnt.com cloudkey-stable InRelease
Hit http://www.ubnt.com cloudkey-stable/ubiquiti armhf Packages
Hit http://httpredir.debian.org jessie Release.gpg
Get:3 http://download.zerotier.com jessie/main armhf Packages [2479 B]
Hit http://httpredir.debian.org jessie Release
Hit http://httpredir.debian.org jessie/main armhf Packages
Hit http://httpredir.debian.org jessie/contrib armhf Packages
Hit http://httpredir.debian.org jessie/non-free armhf Packages
Get:4 http://security.debian.org jessie/updates/main armhf Packages [695 kB]
Hit http://security.debian.org jessie/updates/contrib armhf Packages
Hit http://security.debian.org jessie/updates/non-free armhf Packages
Fetched 764 kB in 1s (764 KB/s)
Reading package lists... Done
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following NEW packages will be installed:
  zerotier-one
0 upgraded, 1 newly installed, 0 to remove and 2 not upgraded.
Need to get 763 kB of archives.
After this operation, 2366 kB of additional disk space will be used.
Get:1 http://download.zerotier.com/debian/jessie/ jessie/main zerotier-one armhf 1.4.6 [763 kB]
Fetched 763 kB in 44s (17.3 kB/s)
Selecting previously unselected package zerotier-one.
(Reading database ... 23329 files and directories currently installed.)
Preparing to unpack .../zerotier-one_1.4.6_armhf.deb ...
Unpacking zerotier-one (1.4.6) ...
Processing triggers for systemd (230-7~bpo8+2.ubnt+1) ...
Setting up zerotier-one (1.4.6) ...
Processing triggers for systemd (230-7~bpo8+2.ubnt+1) ...

*** Enabling and starting zerotier-one service...
Synchronizing state of zerotier-one.service with SysV service script with /lib/systemd/systemd-sysv-install.
Executing: /lib/systemd/systemd-sysv-install enable zerotier-one

*** Waiting for identity generation...

*** Success! You are ZeroTier address [ e50a7c7fc2 ].

Run zerotier-cli to see if everything works:

zerotier-cli
ZeroTier One version 1.4.6 build 0 (platform 1 arch 3)
Copyright (c) 2019 ZeroTier, Inc.
Licensed under the ZeroTier BSL 1.1 (see LICENSE.txt)
Usage: zerotier-cli [-switches] <command/path> [<args>]

Please note after upgrading the Cloud Key firmware, you need to reinstall the Zerotier One package. And if you got the following error when trying to reinstall the package:

*** Enabling and starting zerotier-one service...
Synchronizing state of zerotier-one.service with SysV service script with /lib/systemd/systemd-sysv-install.
Executing: /lib/systemd/systemd-sysv-install enable zerotier-one

*** Waiting for identity generation...

Press control – C and execute the following to restart the service and rejoin the Zerotier network:

systemctl restart zerotier-one
systemctl status zerotier-one
zerotier-cli info
200 info 8ade3af9ef 1.4.6 ONLINE
zerotier-cli join eda9f5dbfe94adbe
200 join OK
# ...then approve it in your Zerotier dashboard
# list network
zerotier-cli listnetworks -j

Fixing TXTRDATATooLong Errors for AWS Route 53

RFC 4408 3.1.3 says

....
     IN TXT "v=spf1 .... first" "second string..."

   MUST be treated as equivalent to

      IN TXT "v=spf1 .... firstsecond string..."

   SPF or TXT records containing multiple strings are useful in
   constructing records that would exceed the 255-byte maximum length of
   a string within a single TXT or SPF RR record.

so if you are getting error “TXTRDATATooLong” a solution for you will be splitting it into multiple strings within the same record set. For example, instead of:

"v=DKIM1; k=rsa; g=*; s=email; h=sha1; t=s; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDx2zIlneFcE2skbzXjq5GudbHNntCGNN9A2RZGC/trRpTXzT/+oymxCytrEsmrwtvKdbTnkkWOxSEUcwU2cffGeaMxgZpONCu+qf5prxZCTMZcHm9p2CwCgFx3
reSF+ZmoaOvvgVL5TKTzYZK7jRktQxPdTvk3/yj71NQqBGatLQIDAQAB;"

you can pick a split point where each part is less than 255 characters long and put [double quote][space][double quote]

for example I tried:

"v=DKIM1; k=rsa; g=*; s=email; h=sha1; t=s; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDx2zIlneFcE2skbzXjq5GudbHNntCGNN9A2RZGC/trRpTXzT/+oymxCytrEsmrwtvKdbTnkkWOxSEUcwU2cffGeaMxgZpONCu+qf5prxZCT" "MZcHm9p2CwCgFx3reSF+ZmoaOvvgVL5TKTzYZK7jRktQxPdTvk3/yj71NQqBGatLQIDAQAB;"

and as a result I’ve got:

dig -t TXT long.xxxxxx.yyyy @ns-iiii.awsdns-jj.org.
;; ANSWER SECTION:
long.xxxxxxx.yyyy. 300    IN      TXT     "v=DKIM1\; k=rsa\; g=*\; s=email\; h=sha1\; t=s\; p=MIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDx2zIlneFcE2skbzXjq5GudbHNntCGNN9A2RZGC/trRpTXzT/+oymxCytrEsmrwtvKdbTnkkWOxSEUcwU2cffGeaMxgZpONCu+qf5prxZCT" "MZcHm9p2CwCgFx3reSF+ZmoaOvvgVL5TKTzYZK7jRktQxPdTvk3/yj71NQqBGatLQIDAQAB\;"

Note that returned TXT contains [double quote][space][double quote] , however the RFC above mandates that string to be treated as the same as concatenated one.

Note that your example does the same too on 128 character boundary

dig s2048._domainkey.yahoo.com TXT                                                                                                                                      /workspace/stepany-HaasControlAPI-development
;; Truncated, retrying in TCP mode.

; <<>> DiG 9.4.2 <<>> s2048._domainkey.yahoo.com TXT
;; global options:  printcmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 61356
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 5, ADDITIONAL: 5

;; QUESTION SECTION:
;s2048._domainkey.yahoo.com.    IN      TXT

;; ANSWER SECTION:
s2048._domainkey.yahoo.com. 61881 IN    TXT     "k=rsa\; t=y\; p=MIIBIjANBgkqhkiG9w0BAQEFAAOCAQ8AMIIBCgKCAQEAuoWufgbWw58MczUGbMv176RaxdZGOMkQmn8OOJ/HGoQ6dalSMWiLaj8IMcHC1cubJx2gz" "iAPQHVPtFYayyLA4ayJUSNk10/uqfByiU8qiPCE4JSFrpxflhMIKV4bt+g1uHw7wLzguCf4YAoR6XxUKRsAoHuoF7M+v6bMZ/X1G+viWHkBl4UfgJQ6O8F1ckKKoZ5K" "qUkJH5pDaqbgs+F3PpyiAUQfB6EEzOA1KMPRWJGpzgPtKoukDcQuKUw9GAul7kSIyEcizqrbaUKNLGAmz0elkqRnzIsVpz6jdT1/YV5Ri6YUOQ5sN5bqNzZ8TxoQlkb" "VRy6eKOjUnoSSTmSAhwIDAQAB\; n=A 2048 bit key\;"

Google Fi、Google Voice、Google Hangouts 使用技巧与细节

最近国内 Lycamobile 翻车,政策改动导致大量在国内漫游的 Lyca 号无信号,只能购买 ¥19/m 的套餐才可以,但部分人反应即便买了套餐依然无任何信号,因此只能上 Google Fi 的车,然而 Google Fi 在 iOS 上依然有些问题,加上 Google Voice、Google Hangouts 产品迭代更替的混乱,使用起来有许多坑,在这里记录一下

配置

  • 港版 iPhone Xs Max,iOS 12.3.1
  • 主卡槽(正面卡槽)为 Google Fi 实体卡,已激活
  • 副卡槽(背面卡槽)为普通联通 4G 卡
  • 系统上已安装 Google Fi、Google Hangouts、Google Voice 这几个 apps
  • Surge 全局代理,美国 IP 地址

Google Fi

这个 app 做的总体还不错,但有几点需要注意:

  • 不要过于指望 Google Fi 中的 voicemail,因为根据使用观察 Google Fi 中的 voicemail 时效性非常差,延迟大概在 15 分钟之久,也就是说在对方给你留言完毕并挂断电话之后,你的 Google Fi app 不会马上出现对方的 voicemail,这就很坑爹了,在有紧急电话的时候会漏掉不少重要电话。为什么我要强调这个时效性,后面的 Hangouts 部分有更多说明
  • Google Fi app 你哪怕开了「后台应用程序刷新」,也无法收到 voicemail 的推送通知,也许跟第一条有关,也许是我个别现象,目前我必须打开 Google Fi app,切换到 Voicemail 标签,稍等几秒后才能刷新出来的新的 voicemail

Google Hangouts

这个 app 在一定程度上会对 Google Fi 用户造成迷惑,主要有以下几点:

  • 以下结论基于你默认开启 Hangouts 里的 Answer on lock screen 设置
  • 如果你开启了 Settings – Phone number – Incoming phone calls(该功能描述为:Ring Hangouts for incoming phone calls made to your Google Fi number.),那么在其他人打给你的 Fi 号码时,会优先显示 Hangouts 的接听界面,此时:
    • 如果你不接电话:
      • 在系统自带的电话 app 下,会出现两条未接,一条来自运营商本身,一条来自 Google Hangouts,标记为 Hangouts Audio
      • 如果你已经开启了 iOS 的 Continuity,即「在附近设备接听」功能,其他苹果设备上依然会收到运营商的来电提醒
      • 不论您是否开启 Incoming phone calls 选项,如果你同时开启了网页版的 Hangouts,网页版都会收到提示音
    • 如果你通过 Hangouts 的界面接听:
      • 可以提供更好的音质,起码优于目前运营商的音质
      • 在接听成功后的数秒内,你会看到系统电话界面闪一下,出现「挂断并接听/等待」的选项,然后数秒后又消失,应该是系统电话与 Hangouts 界面冲突所致
      • 接听完成后你会看到系统电话中 Hangouts Audio 的记录标记为已接听,运营商来电标记为未接听
    • 如果你通过运营商来电接听:
      • 如果你是苹果党,则可以方便的通过「在附近设备接听」功能在任意设备上接听
      • 接听完成后你会看到系统电话中 Hangouts Audio 的记录标记为未接听,运营商来电标记为已接听
    • 建议:对于电话送达率要求不高,或者 Fi 信号比较好的区域,不建议开启此选项,每次来电都出现两条记录还是比较烦的
  • 如果你开启了 Settings – Phone number – Messages(该功能描述为:Show SMS and voicemail in Hangouts Learn more),那么在别人:
    • 因你未接电话对方给你发 voicemail 时:
      • 不像我上面提到的 Google Fi app,voicemail 会在对方留言完毕挂掉电话后,几乎实时出现在 Hangouts 的聊天记录中
      • Voicemail 依然会同步到 Google Fi app 中
    • 给你 Fi 号码发送短信时:
      • 短信将直接出现在 Hangouts 中,包括网页版 Hangouts,多端同步
      • 短信将不再出现在系统自带的 Messages 中,导致 Continuity 功能(即 Text Message Forwarding)不可用,无法在 macOS 上接收短信,但你可以正常通过 iOS、macOS 自带的 Messages 给对方发短信
      • 如果对方是通过 Hangouts 给你发带图片的消息时,你同样可以在 Hangouts 中收到
    • 建议:如果是苹果全家桶的重度用户,此选项也不建议开启,开启此选项会丢掉不少便利性。但在关键时刻,比如信号不好但必须接一个重要的短信时,可以临时开启此选项

Google Voice

  • 当你激活了 Google Fi 后,iOS 上的 Google Voice 将不再可用,打开后会出现一行提示告诉你请去 Google Fi 上操作。但如果你打开电脑版的 fi.google.com,在左下角依然可以进入老版本的 Google Voice 网页版
  • 但此时你可以选择切换账户,用另外一个有 Google Voice 号码但没开启 Google Fi 的 Google 账户继续使用 Google Voice app
  • 根据上面 Google Fi 部分的说明,如果 voicemail 对你很重要,建议用电脑打开旧版本的 Google Voice 页面,去 Settings – Voicemail & Text 下勾选 Alert me when I have new voicemails 的邮件通知,邮件通知基本是在对方留言完毕挂电话后实时推送的,此选项不像上面的 Hangouts 那样有副作用,因此有需求的人这个选项强烈建议开启

硬件/系统本身

目前观察到的特征:

  • 当主卡(正面插槽)为联通,副卡(背面插槽)为 Google Fi 的情况下,双卡信号都非常差,在信号不强的区域经常会双双无信号
  • 因此在原手机号为联通的情况下,建议主卡 Google Fi,副卡联通,此时不管是用哪张卡当流量卡/通话卡,都可以获得「较好」的信号
  • 为什么是「较好」的信号呢?因为这代 iPhone 基带的问题,如果你只装单张卡,会获得「更好」的信号
  • 目前我只知道只有 Pixel 可以原生支持 Google Fi 的 Wi-Fi Calling,因此不介意用 Android 的情况下,可以考虑买个 Pixel 专门跑 Google Fi,也可以避免上面 Hangouts 各种诡异的问题,但代价是不能用 iOS 的 Continuity 特性了
